Swing Gate Opener - 24V DC Motor

Product Overview

The Swing Gate Opener is designed for automatic operation of swing gates, offering powerful performance and reliable operation for both residential and commercial applications. Powered by a 24V DC motor, it provides smooth and efficient movement of gates weighing up to 350 kg per leaf. The opener features a turbine gear structure for durability and optimal performance, with a high thrust capacity of up to 3500N.

Key Features

• 24V DC Motor: Energy-efficient and powerful, ensuring smooth and reliable operation.
• Rated Current: 2A for continuous operation, with a maximum operating current of 5.5A (for 10 seconds).
• Turbine Gear Structure: Provides high reliability and reduces wear and tear for long-lasting operation.
• Maximum Load Capacity: Supports gates up to 350 kg per single leaf.
• Maximum Thrust: 3500N for robust performance.
• Rated Thrust: 3000N, suitable for most residential and light commercial applications.
• Working Stroke: 350mm, allowing smooth gate movement.
• Working Cycle: 20% duty cycle, ideal for moderate use.
• Temperature Range: Operates in a wide range of environments from -20°C to 50°C.
• Maximum Door Length: Suitable for gates up to 4 meters in length per single door.

Technical Specifications

• Motor Type: 24V DC Motor
• Rated Current: 2A
• Maximum Current: 5.5A (maximum for 10 seconds)
• Gear Structure: Turbine gear
• Maximum Load: 350 kg per single leaf door
• Maximum Power Consumption: 144W
• Maximum Thrust: 3500N
• Rated Thrust: 3000N
• Working Stroke: 350mm
• Motor Size: 844mm x 115mm x 106mm
• Motor Weight: 6.25 kg
• Operating Temperature: -20°C to 50°C
• Motor Power Input: 24V DC
• Working Cycle: 20%

Applications

• Residential Swing Gates
• Commercial Entrance Gates
• Industrial Gates
• Driveway Gates

Benefits

• Efficient Performance: The 24V DC motor ensures low power consumption while delivering powerful thrust for gate movement.
• Durability: The turbine gear structure is designed for high durability and minimal maintenance.
• Versatility: Capable of handling gates up to 350 kg per leaf and lengths up to 4 meters, making it suitable for a wide range of gates.
• Safety: Built-in thermal protection to prevent overheating during extended operation.
• Temperature Tolerance: Operates in a wide temperature range, from -20°C to 50°C, suitable for both hot and cold climates.

Installation and Maintenance Tips

1. Proper Mounting: Ensure the motor is securely mounted to avoid mechanical failure during operation.
2. Check Gate Alignment: Misaligned gates can cause excessive strain on the motor. Make sure the gate is aligned correctly before installation.
3. Periodic Lubrication: Lubricate the mechanical components regularly to ensure smooth operation.
4. Check Power Supply: Ensure the power supply is within the 24V DC range for optimal motor performance.
5. Temperature Monitoring: Keep the motor in a place where it is protected from extreme weather, especially during hot or cold conditions.
